Sealed Power

Compare
  • FEDH815DCP40 Cast Piston Set

    Sealed Power

    Part #: H815DCP 40

    FEDH815DCP40 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.0000 IN
    pdm:Compression Height: 1.550 IN
    pdm:Head Illustration: 29
    pdm:Head Type: Recessed Head .098" deep x 2.771 dia. w/4 valve reliefs; DUROSHIELD~ skirt coated piston
    pdm:Oil Ring Thickness: 3.00 MM
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.040 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Type: P or F
    pdm:Piston Material: Hypereutectic
    pdm:Second Compression Ring Thickness: 1.50 MM
    pdm:Top Compression Ring Thickness: 1.50 MM
    pdm:line_code: FED
    pdm:internal_sku: FEDH815DCP40
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Recessed
    pdm:Prop 65 Label (Yes/No): No
    $31.04
  • FEDH811CP40 Cast Piston Set

    Sealed Power

    Part #: H811CP40

    FEDH811CP40 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 3.9375 IN
    pdm:Compression Height: 2.125 IN
    pdm:Head Illustration: 56
    pdm:Head Type: Domed Head w/1 valve relief; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.040 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Type: P
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9894 IN
    pdm:Piston Pin Outside Diameter: 25.131 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Third Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0937 IN
    pdm:Weight W Pin Gram: 00843.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH811CP40
    pdm:Piston Head Type: Dome
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $53.41
  • FEDH816CP30 Cast Piston Set

    Sealed Power

    Part #: H816CP30

    FEDH816CP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.0000 IN
    pdm:Bore Diameter: 101.6 MM
    pdm:Compression Height: 1.595 IN
    pdm:Head Illustration: 26
    pdm:Head Type: Flat Head w/4 valve reliefs; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 4.00 MM
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9122 IN
    pdm:Piston Pin Outside Diameter: 23.17 MM
    pdm:Second Compression Ring Thickness: 1.50 MM
    pdm:Top Compression Ring Thickness: 1.50 MM
    pdm:Weight W Pin Gram: 00731.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH816CP30
    pdm:Piston Head Type: Flat
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $34.18
  • FEDH699DCP30 Cast Piston Set

    Sealed Power

    Part #: H699DCP 30

    FEDH699DCP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.0000 IN
    pdm:Compression Height: 1.550 IN
    pdm:Head Illustration: 29
    pdm:Head Type: Recessed Head .098" deep x 2.771 dia. w/4 valve reliefs; DUROSHIELD~ skirt coated piston
    pdm:Oil Ring Thickness: 3.00 MM
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Piston Material: Hypereutectic
    pdm:Second Compression Ring Thickness: 1.50 MM
    pdm:Top Compression Ring Thickness: 1.50 MM
    pdm:line_code: FED
    pdm:internal_sku: FEDH699DCP30
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Recessed
    pdm:Prop 65 Label (Yes/No): No
    $37.78
  • FEDH825CP30 Cast Piston Set

    Sealed Power

    Part #: H825CP30

    FEDH825CP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 3.8750 IN
    pdm:Bore Diameter: 99.0 MM
    pdm:Compression Height: 1.592 IN
    pdm:Head Illustration: 12
    pdm:Head Type: Recessed Head .116 deep; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.931 IN
    pdm:Piston Pin Outside Diameter: 23.647 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 00568.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH825CP30
    pdm:Piston Head Type: Recessed
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $54.37
  • FEDH727CP60 Cast Piston Set

    Sealed Power

    Part #: H727CP60

    FEDH727CP60 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.2500 IN
    pdm:Bore Diameter: 107.95 MM
    pdm:Compression Height: 1.625 IN
    pdm:Head Illustration: 10
    pdm:Head Type: Recessed Head .070 deep x 2.000 dia. w/2 valve reliefs; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.060 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.04
    pdm:Pin Offset (MM): 1.016
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9893 IN
    pdm:Piston Pin Outside Diameter: 25.128 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:line_code: FED
    pdm:internal_sku: FEDH727CP60
    pdm:Piston Head Type: Recessed
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $52.01
  • FEDH802CP30 Cast Piston Set

    Sealed Power

    Part #: H802CP30

    FEDH802CP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 3.8750 IN
    pdm:Bore Diameter: 99.0 MM
    pdm:Compression Height: 1.592 IN
    pdm:Head Illustration: 12
    pdm:Head Type: Recessed Head .116 deep; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 4.00 MM
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.931 IN
    pdm:Piston Pin Outside Diameter: 23.647 MM
    pdm:Second Compression Ring Thickness: 1.50 MM
    pdm:Top Compression Ring Thickness: 1.50 MM
    pdm:Weight W Pin Gram: 00564.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH802CP30
    pdm:Piston Head Type: Recessed
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $37.88
  • FEDH661CP30 Cast Piston Set

    Sealed Power

    Part #: H661CP30

    FEDH661CP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.2500 IN
    pdm:Bore Diameter: 107.95 MM
    pdm:Compression Height: 1.625 IN
    pdm:Dome Volume CC: Negative 002.0
    pdm:Head Illustration: 5
    pdm:Head Type: Flat Head w/2 valve reliefs; Use E424K30 ring set for H661CP100; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9893 IN
    pdm:Piston Pin Outside Diameter: 25.128 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 00730.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH661CP30
    pdm:Piston Head Type: Flat
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $32.83
  • FEDH423DCP60 Cast Piston Set

    Sealed Power

    Part #: H423DCP 60

    FEDH423DCP60 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.060 IN
    pdm:Compression Height: 1.548 IN
    pdm:Dome Volume CC: Negative 12.3
    pdm:Head Illustration: 29
    pdm:Head Type: 0.098 dish, 4 reliefs; Use w/Lock Ring LR-63; DUROSHIELD~ skirt coated piston
    pdm:Lock Ring: Not Incl.
    pdm:Minimum Clearance: 0.0010
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.060 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Type: F
    pdm:Pin Weight Gram: 149
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.927 IN
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 690
    pdm:Weight w/o Pin Gram: 541
    pdm:line_code: FED
    pdm:internal_sku: FEDH423DCP60
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Dish
    pdm:Prop 65 Label (Yes/No): No
    $26.60
  • FEDH661CP40 Cast Piston Set

    Sealed Power

    Part #: H661CP40

    FEDH661CP40 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.2500 IN
    pdm:Bore Diameter: 107.95 MM
    pdm:Compression Height: 1.625 IN
    pdm:Dome Volume CC: Negative 002.0
    pdm:Head Illustration: 5
    pdm:Head Type: Flat Head w/2 valve reliefs; Use E424K30 ring set for H661CP100; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.040 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9893 IN
    pdm:Piston Pin Outside Diameter: 25.128 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 00730.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH661CP40
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Flat
    pdm:Prop 65 Label (Yes/No): No
    $32.83
  • FEDH653CP30 Cast Piston Set

    Sealed Power

    Part #: H653CP30

    FEDH653CP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.0000 IN
    pdm:Bore Diameter: 101.6 MM
    pdm:Compression Height: 1.765 IN
    pdm:Dome Volume CC: Negative 019.0
    pdm:Head Illustration: 14
    pdm:Head Type: Recessed Head .190 deep oblong; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Pin Type: P
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9122 IN
    pdm:Piston Pin Outside Diameter: 23.17 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 00708.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH653CP30
    pdm:Piston Head Type: Recessed
    pdm:Grade Type: Premium
    pdm:Prop 65 Label (Yes/No): No
    $27.67
  • FEDH654CP30 Cast Piston Sold in sets only

    Sealed Power

    Part #: H654CP30

    FEDH654CP30 Cast Piston Sold in sets only

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.0000 IN
    pdm:Bore Diameter: 101.6 MM
    pdm:Compression Height: 1.599 IN
    pdm:Dome Volume CC: Negative 004.0
    pdm:Head Illustration: 29
    pdm:Head Type: Recessed Head .030 deep x 2.500 dia. w/4 valve reliefs; DUROSHIELD~ skirt coated piston
    pdm:Minimum Clearance: See Piston Fitting Information on carton label
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Pin Type: P
    pdm:Piston Material: Hypereutectic
    pdm:Piston Pin Outside Diameter: 0.9122 IN
    pdm:Piston Pin Outside Diameter: 23.17 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 00729.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FEDH654CP30
    $18.03

Why Buy Vehicle Parts from Northern Auto Parts?

40+ Years Experience


Northern Auto Parts has been providing auto parts for all makes and models for over 40 years. We have everything you need to keep your car, truck, or SUV running in peak condition. For engine builders, Northern Auto Parts is one of the best online sources for kits.

Trusted Source for Name-Brand Parts


Northern Auto Parts is recognized by many as the best online source for rebuild components. We carry a wide variety of name-brand components, so you can find the exact parts you need to repair or replace any part of your vehicle. From engine components to exterior parts, we have a vast selection to choose from.

Competitive Pricing


We are committed to affordability without compromising on quality. Our prices provide the best value for your money, whether you’re an automotive technician or a DIY enthusiast.
