Sealed Power

(Showing 12 of 279)

Sealed Power Engine Parts from Northern Auto Parts

Renowned for their durability and precision, Sealed Power parts are engineered to enhance your engine's efficiency and power. Our selection includes everything from Sealed Power bearings and pistons to rings and gaskets, designed to meet the rigorous demands of both daily driving and high-performance applications. We trust Sealed Power for some components in our engine kits, and we stand by their quality and price.

Elevate your vehicle's performance with Northern Auto Parts' catalog of Sealed Power engine components.

Compare
Show 12 24 36 48 96
  • FED368P40 Cast Piston Set

    Sealed Power

    Part #: 368P40

    FED368P40 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.1875 IN
    pdm:Bore Diameter: 106.4 MM
    pdm:Compression Height: 1.947 IN
    pdm:Head Illustration: 28
    pdm:Head Type: Recessed Head .090 deep x 3.500 dia. - 9.9:1 C.R.
    pdm:Minimum Clearance: 0.0015 @ bottom of skirt
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.040 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Cast Aluminum
    pdm:Piston Pin Outside Diameter: 0.9997 IN
    pdm:Piston Pin Outside Diameter: 25.392 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:line_code: FED
    pdm:internal_sku: FED368P40
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Recessed
    $59.59
  • FED3760A Con Rod Bearing Pair

    Sealed Power

    Part #: 3760A

    FED3760A Con Rod Bearing Pair

    Engine Make: Federal Mogul
    pdm:Grade Type: Premium
    pdm:Housing Bore Max (Inch): 2.3745 IN
    pdm:Design Feature 1: Standard Size
    pdm:Housing Bore Max (MM): 60.3120 MM
    pdm:Oil Clearance Max (Inch): 0.0030 IN
    pdm:Housing Bore Min (MM): 60.3000 MM
    pdm:Housing Bore Min (Inch): 2.3740 IN
    pdm:Oil Clearance Min (MM): 0.0180 MM
    pdm:Overall Length Max (Inch): 0.7210 IN
    pdm:Oil Clearance Max (MM): 0.0760 MM
    pdm:Oil Clearance Min (Inch): 0.0007 IN
    pdm:Standard Shaft Max (Inch): 2.2495 IN
    pdm:Standard Shaft Max (MM): 57.1370 MM
    pdm:Overall Length Max (MM): 18.3100 MM
    pdm:Standard Shaft Min (Inch): 2.2487 IN
    pdm:Wall thickness Max (MM): 1.5720 MM
    pdm:Standard Shaft Min (MM): 57.1170 MM
    pdm:Part Description: Engine Connecting Rod Bearing
    pdm:internal_sku: FED3760A
    pdm:Wall Thickness Max (Inch): 0.0619 IN
    pdm:line_code: FED
    $5.67
  • FED3810CP Con Rod Bearing Pair

    Sealed Power

    Part #: 3810CP

    FED3810CP Con Rod Bearing Pair

    Engine Make: Federal Mogul
    pdm:Design Feature 1: Standard Size
    pdm:Housing Bore Max (Inch): 2.6910 IN
    pdm:Grade Type: Premium
    pdm:Housing Bore Min (Inch): 2.6905 IN
    pdm:Housing Bore Max (MM): 68.3510 MM
    pdm:Oil Clearance Max (Inch): 0.0036 IN
    pdm:Housing Bore Min (MM): 68.3390 MM
    pdm:Oil Clearance Min (MM): 0.0280 MM
    pdm:Oil Clearance Max (MM): 0.0910 MM
    pdm:Oil Clearance Min (Inch): 0.0011 IN
    pdm:Overall Length Max (Inch): 0.8880 IN
    pdm:Standard Shaft Min (Inch): 2.4980 IN
    pdm:Overall Length Max (MM): 22.5600 MM
    pdm:Standard Shaft Max (Inch): 2.4990 IN
    pdm:Part Description: Engine Connecting Rod Bearing
    pdm:Wall Thickness Max (Inch): 0.0952 IN
    pdm:Standard Shaft Max (MM): 63.4750 MM
    pdm:Wall thickness Max (MM): 2.4180 MM
    pdm:Standard Shaft Min (MM): 63.4490 MM
    pdm:line_code: FED
    pdm:internal_sku: FED3810CP
    $13.34
  • FED3814Y20 Piston Pin Bush Set

    Sealed Power

    Part #: 3814Y20

    FED3814Y20 Piston Pin Bush Set

    Engine Make: Federal Mogul
    pdm:Part Description: Engine Piston Wrist Pin Bushing Set
    pdm:Grade Type: Premium
    pdm:Maximum Length: 1.0780 IN
    pdm:Maximum Length: 27.381 MM
    pdm:Maximum Outside Diameter: 1.2355 IN
    pdm:Maximum Inside Diameter: 1.1110 IN
    pdm:Maximum Outside Diameter: 31.382 MM
    pdm:Maximum Inside Diameter: 28.219 MM
    pdm:line_code: FED
    pdm:internal_sku: FED3814Y20
    $8.16
  • FED3814YA20 Piston Pin Bush Set

    Sealed Power

    Part #: 3814YA20

    FED3814YA20 Piston Pin Bush Set

    Engine Make: Federal Mogul
    pdm:Maximum Inside Diameter: 1.3092 IN
    pdm:Maximum Length: 1.1620 IN
    pdm:internal_sku: FED3814YA20
    pdm:Maximum Inside Diameter: 33.254 MM
    pdm:Grade Type: Premium
    pdm:Maximum Outside Diameter: 36.416 MM
    pdm:Maximum Outside Diameter: 1.4337 IN
    pdm:Maximum Length: 29.515 MM
    pdm:Part Description: Engine Piston Wrist Pin Bushing Set
    pdm:line_code: FED
    $7.86
  • FED381NP40 Cast Piston Set

    Sealed Power

    Part #: 381NP40

    FED381NP40 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.0500 IN
    pdm:Bore Diameter: 101.6 MM
    pdm:Compression Height: 1.660 IN
    pdm:Head Illustration: 31
    pdm:Head Type: Recessed Head .097 deep x 2.620 dia. w/4 valve pockets
    pdm:Minimum Clearance: 0.0015 @ 2.630 from top of head
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.040 IN
    pdm:Part Description: Engine Piston
    pdm:Piston Material: Cast Aluminum
    pdm:Piston Pin Outside Diameter: 0.9753 IN
    pdm:Piston Pin Outside Diameter: 24.773 MM
    pdm:Second Compression Ring Thickness: 0.0937 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:line_code: FED
    pdm:internal_sku: FED381NP40
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Recessed
    $27.92

  • Sealed Power

    Part #: 3860P

    FED3860P Con Rod Bearing Pair

    Engine Make: Federal Mogul
    pdm:Oil Clearance Min (Inch): 0.0014 IN
    pdm:Oil Clearance Max (Inch): 0.0042 IN
    pdm:Housing Bore Min (Inch): 2.5246 IN
    pdm:Oil Clearance Min (MM): 0.0360 MM
    pdm:Design Feature 1: Standard Size
    pdm:Oil Clearance Max (MM): 0.1070 MM
    pdm:Grade Type: Premium
    pdm:Housing Bore Min (MM): 64.1250 MM
    pdm:Housing Bore Max (MM): 64.1500 MM
    pdm:Overall Length Max (Inch): 0.9020 IN
    pdm:Housing Bore Max (Inch): 2.5256 IN
    pdm:line_code: FED
    pdm:Standard Shaft Max (MM): 60.9400 MM
    pdm:Standard Shaft Min (Inch): 2.3982 IN
    pdm:Wall Thickness Max (Inch): 0.0620 IN
    pdm:Standard Shaft Max (Inch): 2.3992 IN
    pdm:Wall thickness Max (MM): 1.5750 MM
    pdm:Standard Shaft Min (MM): 60.9140 MM
    pdm:Part Description: Engine Connecting Rod Bearing
    pdm:Overall Length Max (MM): 22.9100 MM
    pdm:internal_sku: FED3860P
    $9.44
  • FED3864Y20 Piston Pin Bush Set

    Sealed Power

    Part #: 3864Y20

    FED3864Y20 Piston Pin Bush Set

    Engine Make: Federal Mogul
    pdm:Maximum Inside Diameter: 31.026 MM
    pdm:Maximum Inside Diameter: 1.2215 IN
    pdm:Maximum Length: 25.410 MM
    pdm:Design Feature 2: .020" extra bore stock
    pdm:Maximum Length: 1.0004 IN
    pdm:Maximum Outside Diameter: 1.3047 IN
    pdm:Grade Type: Premium
    pdm:Part Description: Engine Piston Wrist Pin Bushing Set
    pdm:Maximum Outside Diameter: 33.139 MM
    pdm:internal_sku: FED3864Y20
    pdm:line_code: FED
    $10.90
  • FED392AP30 Cast Piston Set

    Sealed Power

    Part #: 392AP30

    FED392AP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.3125 IN
    pdm:Bore Diameter: 109.5 MM
    pdm:Compression Height: 1.955 IN
    pdm:Head Illustration: 28
    pdm:Head Type: Recessed Head .230 deep x 3.610 dia.
    pdm:Minimum Clearance: 0.0015 @ 3.100 from top of head
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.06
    pdm:Pin Offset (MM): 1.524
    pdm:Piston Material: Cast Aluminum
    pdm:Piston Pin Outside Diameter: 0.9999 IN
    pdm:Piston Pin Outside Diameter: 25.397 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:line_code: FED
    pdm:internal_sku: FED392AP30
    pdm:Piston Head Type: Recessed
    pdm:Grade Type: Premium
    $51.77
  • FED4-3960CPA Con Rod Bearing Set

    Sealed Power

    Part #: 4-3960CPA

    FED4-3960CPA Con Rod Bearing Set

    Engine Make: Federal Mogul
    pdm:Overall Length Max (Inch): 0.8600 IN
    pdm:Design Feature 1: Standard Size
    pdm:Housing Bore Max (Inch): 2.2054 IN
    pdm:Grade Type: Premium
    pdm:Oil Clearance Min (Inch): 0.0010 IN
    pdm:Oil Clearance Max (MM): 0.0860 MM
    pdm:Standard Shaft Min (MM): 52.9740 MM
    pdm:Standard Shaft Max (Inch): 2.0862 IN
    pdm:Housing Bore Min (MM): 55.9970 MM
    pdm:Housing Bore Min (Inch): 2.2046 IN
    pdm:Housing Bore Max (MM): 56.0170 MM
    pdm:line_code: FED
    pdm:Standard Shaft Min (Inch): 2.0856 IN
    pdm:Wall Thickness Max (Inch): 0.0587 IN
    pdm:Oil Clearance Max (Inch): 0.0034 IN
    pdm:internal_sku: FED4-3960CPA
    pdm:Standard Shaft Max (MM): 52.9890 MM
    pdm:Part Description: Engine Connecting Rod Bearing Set
    pdm:Wall thickness Max (MM): 1.4910 MM
    pdm:Oil Clearance Min (MM): 0.0250 MM
    pdm:Overall Length Max (MM): 21.8400 MM
    $16.26
  • FED4-5055A Con Rod Bearing Set

    Sealed Power

    Part #: 4-5055A

    FED4-5055A Con Rod Bearing Set

    Engine Make: Federal Mogul
    pdm:Design Feature 1: Standard Size
    pdm:Grade Type: Premium
    pdm:Part Description: Engine Connecting Rod Bearing Set
    pdm:line_code: FED
    pdm:internal_sku: FED4-5055A
    $26.09
  • FED400AP30 Cast Piston Set

    Sealed Power

    Part #: 400AP30

    FED400AP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 4.1250 IN
    pdm:Bore Diameter: 104.78 MM
    pdm:Compression Height: 1.540 IN
    pdm:Dome Volume CC: Negative 025.0
    pdm:Head Illustration: 28
    pdm:Head Type: Recessed Head .160 deep x 3.445 dia. - 8.5:1 C.R.
    pdm:Minimum Clearance: 0.001 @ 1.830 from top of head
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.03
    pdm:Pin Offset (MM): 0.762
    pdm:Pin Type: P
    pdm:Piston Material: Cast Aluminum
    pdm:Piston Pin Outside Diameter: 0.9275 IN
    pdm:Piston Pin Outside Diameter: 23.559 MM
    pdm:Second Compression Ring Thickness: 0.0781 IN
    pdm:Top Compression Ring Thickness: 0.0781 IN
    pdm:Weight W Pin Gram: 00785.+/- 00.
    pdm:line_code: FED
    pdm:internal_sku: FED400AP30
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Recessed
    $22.18
