Federal-Mogul

(Showing 12 of 254)

Federal-Mogul Parts at Northern Auto Parts

Enhance your vehicle's performance with our selection of Federal-Mogul parts, known for top-notch quality and durability, complimenting our engine kit selection.

Northern Auto Parts offers a wide range of Federal-Mogul components, from engine bearings and gaskets to pistons and piston rings, ensuring your vehicle gets what it needs to runs smoothly and efficiently. Whether you're working on a classic restoration or maintaining your daily driver, our Federal-Mogul inventory has everything you need to keep your engine in peak condition.

Compare
Show 12 24 36 48 96
  • FED8-3860P Con Rod Bearing Set

    Sealed Power

    Part #: 8-3860P

    FED8-3860P Con Rod Bearing Set

    Engine Make: Federal Mogul
    pdm:Design Feature 1: Standard Size Standard
    pdm:Grade Type: Standard Replacement
    pdm:Housing Bore Min (MM): 64.1250 MM
    pdm:Housing Bore Min (Inch): 2.5246 IN
    pdm:Housing Bore Max (Inch): 2.5256 IN
    pdm:Oil Clearance Max (Inch): 0.0042 IN
    pdm:Housing Bore Max (MM): 64.1500 MM
    pdm:Oil Clearance Min (MM): 0.0360 MM
    pdm:Standard Shaft Max (Inch): 2.3992 IN
    pdm:Overall Length Max (Inch): 0.9020 IN
    pdm:Part Description: Engine Connecting Rod Bearing Set
    pdm:Oil Clearance Min (Inch): 0.0014 IN
    pdm:Overall Length Max (MM): 22.9100 MM
    pdm:Standard Shaft Max (MM): 60.9400 MM
    pdm:Oil Clearance Max (MM): 0.1070 MM
    pdm:Standard Shaft Min (MM): 60.9140 MM
    pdm:internal_sku: FED8-3860P
    pdm:line_code: FED
    pdm:Wall thickness Max (MM): 1.5750 MM
    pdm:Wall Thickness Max (Inch): 0.0620 IN
    pdm:Standard Shaft Min (Inch): 2.3982 IN
    $66.52
  • FED884M Main Bearing Set

    Sealed Power

    Part #: 884M

    FED884M Main Bearing Set

    Engine Make: Federal Mogul
    pdm:Part Description: Engine Crankshaft Main Bearing Set
    pdm:Part Material: Steel backed overplated bronze alloy
    pdm:internal_sku: FED884M
    pdm:Standard Size: Standard
    pdm:Grade Type: Standard Replacement
    pdm:line_code: FED
    $101.47
  • FED88NP30 Cast Piston Set

    Sealed Power

    Part #: 88NP30

    FED88NP30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 3.1250 IN
    pdm:Bore Diameter: 79.2 MM
    pdm:Compression Height: 2.167 IN
    pdm:Head Illustration: 23
    pdm:Head Type: Flat Head - 6.7:1 C.R.
    pdm:Minimum Clearance: 0.0015 @ bottom of skirt
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Piston Material: Cast Aluminum
    pdm:Piston Pin Outside Diameter: 0.812 IN
    pdm:Piston Pin Outside Diameter: 20.625 MM
    pdm:Second Compression Ring Thickness: 0.0937 IN
    pdm:Top Compression Ring Thickness: 0.0937 IN
    pdm:line_code: FED
    pdm:internal_sku: FED88NP30
    pdm:Grade Type: Premium
    pdm:Piston Head Type: Flat
    $38.95
  • FED92P30 Cast Piston Set

    Sealed Power

    Part #: 92P30

    FED92P30 Cast Piston Set

    pdm:Assembly Lubricant Included: No
    pdm:Bore Diameter: 3.7500 IN
    pdm:Bore Diameter: 95.3 MM
    pdm:Compression Height: 2.030 IN
    pdm:Head Illustration: 23
    pdm:Head Type: Flat Head - 7.8:1 C.R.
    pdm:Minimum Clearance: 0.001 @ 3.430 from top of head
    pdm:Oil Ring Thickness: 0.1875 IN
    pdm:Oversized: Yes
    pdm:Oversized Amount: 0.030 IN
    pdm:Part Description: Engine Piston
    pdm:Pin Offset (Inch): 0.078
    pdm:Pin Offset (MM): 1.981
    pdm:Piston Material: Cast Aluminum
    pdm:Piston Pin Outside Diameter: 0.9272 IN
    pdm:Piston Pin Outside Diameter: 23.551 MM
    pdm:Second Compression Ring Thickness: 0.0937 IN
    pdm:Top Compression Ring Thickness: 0.0937 IN
    pdm:line_code: FED
    pdm:internal_sku: FED92P30
    pdm:Grade Type: Standard Replacement
    pdm:Piston Head Type: Flat
    $56.60
  • FED960M Main Bearing Set

    Sealed Power

    Part #: 960M

    FED960M Main Bearing Set

    Engine Make: Federal Mogul
    pdm:Part Alert: Use w/FSM-124S shim set
    pdm:Standard Size: Standard
    pdm:Grade Type: Standard Replacement
    pdm:internal_sku: FED960M
    pdm:line_code: FED
    pdm:Part Material: Steel backed overplated bronze alloy
    pdm:Part Description: Engine Crankshaft Main Bearing Set
    $81.27
  • FED994M Main Bearing Set

    Sealed Power

    Part #: 994M

    FED994M Main Bearing Set

    Engine Make: Federal Mogul
    pdm:Application: O.E. Replacement
    pdm:Displacement: 283, 327
    pdm:Engine Family: Small Block
    pdm:line_code: FED
    pdm:Sizes: Std-1-10-20-30-40
    pdm:Part Description: Engine Crankshaft Main Bearing Set
    pdm:Grade Type: Standard Replacement
    pdm:Manufacture: Chevrolet
    pdm:Material: A-Series aluminum bearings
    pdm:Set Type: Main Set
    pdm:internal_sku: FED994M
    $57.84
  • FEDAT-892 Valve Lifter

    Sealed Power

    Part #: AT-892

    FEDAT-892 Valve Lifter

    Engine Make: Sealed Power
    pdm:Lifter Type: Solid
    pdm:Roller: No
    pdm:internal_sku: FEDAT-892
    pdm:Part Description: Engine Valve Lifter
    pdm:line_code: FED
    $18.45
  • FEDE-1009K Piston Ring Set

    Sealed Power

    Part #: E-1009K

    FEDE-1009K Piston Ring Set

    Engine Make: Sealed Power
    pdm:2nd Ring Material: Ductile Iron w/Phosphate Coating
    pdm:Bore Diameter: 95.50 MM
    pdm:2nd Ring Width: 1.50 MM
    pdm:Oversized: No
    pdm:line_code: FED
    pdm:Top Ring Face Design: Barrel Face
    pdm:Oil Ring Width: 2.50 MM
    pdm:2nd Ring Face Design: High Tensil
    pdm:Oil Ring Design: 3 Piece Flex Vent
    pdm:Part Description: Engine Piston Ring Set
    pdm:Top Ring Material: Steel w/Moly
    pdm:Top Ring Radial Wall Thickness: 0.142 MM
    pdm:internal_sku: FEDE-1009K
    pdm:Top Ring Width: 1.20 MM
    pdm:Cylinder Quantity: 6
    pdm:Ring Set Groove Widths: 1.2 x 1.5 x 2.5 MM
    pdm:File Fit: No
    pdm:Grade Type: Standard Replacement
    $73.32
  • FEDE-978K Piston Ring Set

    Sealed Power

    Part #: E-978K

    FEDE-978K Piston Ring Set

    Engine Make: Sealed Power
    pdm:Oversized: No
    pdm:Oil Ring Design: 3 Piece Flex Vent
    pdm:2nd Ring Face Design: Reverse Torsional
    pdm:Oil Ring Width: 3.00 MM
    pdm:File Fit: No
    pdm:2nd Ring Material: Grey Iron w/Phosphate Coating
    pdm:Cylinder Quantity: 6
    pdm:Bore Diameter: 100.40 MM
    pdm:2nd Ring Width: 1.50 MM
    pdm:line_code: FED
    pdm:Top Ring Radial Wall Thickness: 3.780 MM
    pdm:Top Ring Width: 1.20 MM
    pdm:Top Ring Material: Steel w/Chrome
    pdm:Part Description: Engine Piston Ring Set
    pdm:Ring Set Groove Widths: 1.2 x 1.5 x 3.0 MM
    pdm:Top Ring Face Design: Barrel Face
    pdm:internal_sku: FEDE-978K
    pdm:Grade Type: Standard Replacement
    $101.60
  • FEDE-979K Piston Ring Set

    Sealed Power

    Part #: E-979K

    FEDE-979K Piston Ring Set

    Engine Make: Sealed Power
    pdm:2nd Ring Material: Grey Iron w/Phosphate Coating
    pdm:2nd Ring Face Design: Reverse Torsional
    pdm:2nd Ring Width: 1.50 MM
    pdm:Bore Diameter: 101.60 MM
    pdm:Oil Ring Design: 3 Piece Flex Vent
    pdm:Oil Ring Width: 2.50 MM
    pdm:Cylinder Quantity: 8
    pdm:Part Description: Engine Piston Ring Set
    pdm:File Fit: No
    pdm:Oversized: No
    pdm:Top Ring Face Design: Barrel Face
    pdm:Ring Set Groove Widths: 1.2 x 1.5 x 2.5 MM
    pdm:Top Ring Width: 1.20 MM
    pdm:Top Ring Material: Steel w/Moly
    pdm:internal_sku: FEDE-979K
    pdm:Top Ring Radial Wall Thickness: 3.660 MM
    pdm:line_code: FED
    pdm:Grade Type: Standard Replacement
    $136.34
  • FEDE-984KC Piston Ring Set

    Sealed Power

    Part #: E-984KC

    FEDE-984KC Piston Ring Set

    Engine Make: Sealed Power
    pdm:internal_sku: FEDE-984KC
    pdm:Part Description: Engine Piston Ring Set
    pdm:Oversized: No
    pdm:Cylinder Quantity: 6
    pdm:line_code: FED
    pdm:File Fit: No
    pdm:Grade Type: Standard Replacement
    $29.24
  • Federal Mogul 139M

    Federal Mogul

    Part #: 139M

    Federal Mogul 139M

    Engine Make: Federal Mogul
    $69.68

Why Buy Federal-Mogul Parts from Northern Auto Parts?


Choosing Federal-Mogul parts from Northern Auto Parts means you're investing in quality and reliability. Our extensive selection ensures you find the right parts for any vehicle, backed by Federal Mogul’s reputation for excellence. Trust Northern Auto Parts for your Federal Mogul needs and experience superior performance and durability, keeping your vehicle running smoothly and efficiently. With Northern Auto Parts, you get the right parts at the right time, every time.
