The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all time. They have been powering racing legends and street enthusiasts alike since the early 70s. Their time proven rotor/vane design is known to get the job done in an affordable package.

Tumble polished billet look

Lower housing casting designed for enhanced fuel flow

Motor draws only 3 amps current

Relay kit P/N 12-753 & 7 1/2 amp fuse recommended

Improved design for street/strip applications

Not designed for use on aircraft of any type

Distinctive “Blue” logo

Flows 110 GPH (free flow)

Flows 88 GPH at 9 psi

Maximum pressure is 14 psi

Includes P/N 12-803 fuel pressure regulator

Provides constant fuel flow with no pulsation

Has externally accessible pressure relief valve (max 14 psi)

Rotor/vane pump design is more tolerant of contaminated fuels

Weighs only 3 lbs

Includes mounting bracket

Repair kits are readily available

Can be serviced from the pump end

Not compatible with alcohol or methanol fuels

Use of safety shut-off switch, P/N 12-810, strongly recommended

Not designed or recommended for use with fuel injection systems
