MEL10553ST Oil Pump

Melling Select Performance

    No reviews yet Write a Review
    SKU:
    10553ST
    MPN:
    10553ST
    This item is currently out of stock, but can still be ordered. We will contact you with an estimated delivery date once we receive your order.
    $149.42

    MEL10553ST Oil Pump

    Melling Select Performance

      No reviews yet Write a Review
      SKU:
      10553ST
      MPN:
      10553ST
      This item is currently out of stock, but can still be ordered. We will contact you with an estimated delivery date once we receive your order.
      $149.42
      $149.42
      Upgrade Options:

      Description

      Made in USA. Melling high performance oil pumps provide dependable performance every time in every application under the toughest RPM conditions. The Melling high performance cast iron oil pump series features a doweled housing and cover, extended drive and idler shafts for additional support at increased RPM’s, a screw in relief spring plug, CNC machined cover and housing that is manganese phosphate coated, standard volume and high volume patented billet Shark Tooth gears, and a chrome moly drive shaft with steel guide. Includes lower pressure spring and self locking socket head bolts with wrench for use with bolt on screen pumps. Every Melling high performance oil pump is individually tested for pressure and flow under actual engine operating conditions. Melling high performance Shark Tooth oil pumps are recommended for all applications where a high performance oil pump is needed.
    • Features billet steel "Shark Tooth" helical gears.
    • CNC machined and phosphate coated housing and cover.
    • Pink high pressure spring (M-55A)comes installed with the lower pressure yellow spring (M-55) also included.
    • Includes 12550 chrome moly intermediate shaft with steel guide.

      • Extra Information

      Brand:
      Melling Select Performance
      Engine Make:
      Melling Engine Parts
      Anti-Cavitation:
      No
      Additional Cover Shaft Support:
      No
      Alternate Pressure Springs Included:
      Yes
      Grade Type:
      Performance
      Gear Material:
      Billet Steel
      Gasket Or Seal Included:
      No
      Drive Shaft Included:
      Yes
      Gear Type:
      Shark Tooth Helical Gear
      Drive Type:
      Drive Shaft
      Mounting Hole Quantity:
      2
      Housing Material:
      Cast Iron
      Mounting Hole Diameter:
      0.240 IN
      Height:
      4.250 IN
      Oil Pump Pressure Type:
      High Pressure
      Pickup Tube Diameter:
      0.625 IN
      Width:
      3.110 IN
      Oil Pump Volume Type:
      Standard Volume
      Oil Pump Type:
      Gear
      internal sku:
      MEL10553ST
      line code:
      MEL
      Optional Spring Pressure 2:
      N/A
      Manufactured Pressure:
      (Green) 70 PSI
      Manufactured For:
      GM SBC
      Optional Spring Pressure 1:
      (Yellow) 58 PSI
      Upgrade for Pump Number:
      M-55, M-55A
      Height:
      108.00 MM
      Pickup Tube Diameter:
      16.00 MM
      Screen Information:
      5/8" Press In
      Mounting Hole Diameter:
      6.00 MM
      Width:
      79.00 MM
      Bolts Included:
      No
      Bushing Included:
      No
      Hardware Included:
      No
      Gears Included:
      Yes
      Cover Material:
      Cast Iron
      Cotter Pin Included:
      No
      Inlet Size (mm):
      16.00
      Inlet Size (in):
      0.625
      Governor Spinner Included:
      No
      Guide Included:
      Yes
      Timing Cover Included:
      No
      Spacer Included:
      No
      Pickup Screen Included:
      No
      Nylon Bushing Included:
      No
      O-Ring Included:
      No
      Intermediate Shaft Included:
      Yes
      Pump Cover Included:
      Yes
      Housing Finish:
      Phosphate Coating
      Shaft Material:
      Chromoly Steel
      Washers Included:
      No
