The world famous Red®, Blue® and Black® fuel pumps are the most recognized performance pumps of all times. They have been powering racing legends and street enthusiasts alike since the early 70's. Their time proven rotor/vane design is known to get the job done in an affordable package. Designed with a fume tube for marine use and meets U.S. Coast Guard regulations.

Tumble polished billet look

Lower housing casting designed for enhanced fuel flow.

Improved design for street/strip applications

Distinctive “Black” logo

Compatible with alcohol or methanol fuels

Not designed for use on aircraft of any type.

Flows 140 GPH (free flow)

Flows 120 GPH at 9 psi

Maximum pressure is 14 psi

3/8” NPT inlet and outlet ports

Fuel pressure regulator is required (recommend Holley P/N 12-704 for gasoline & P/N 12-707 for alcohol)

Motor draws only 4 amps current

7 1/2 amp fuse recommended

Provides constant fuel flow with no pulsation

Has externally accessible pressure relief valve (max 14 psi)

Rotor/vane pump design is more tolerant of contaminated fuels

Weighs only 3 lbs

Includes mounting bracket

Repair kits are readily available

Can be serviced from the pump end

Use of safety shut-off switch, P/N 12-810, strongly recommended

Not designed or recommended for use with fuel injection systems

Meets U.S. Coast Guard regulations

Includes Fuel/vapor tube
