HLY300-113

Holley

    No reviews yet Write a Review
    SKU:
    HLY300-113
    This item is currently out of stock, but can still be ordered. We will contact you with an estimated delivery date once we receive your order.
    $862.95

    HLY300-113

    Holley

      No reviews yet Write a Review
      SKU:
      HLY300-113
      This item is currently out of stock, but can still be ordered. We will contact you with an estimated delivery date once we receive your order.
      $862.95
      $862.95
      Upgrade Options:

      Description

      The Holley GM LS3/L92 Modular Hi-Ram Intake Manifold is introduced as a cost-effective alternative to fabricated sheet-metal for high-performance applications where induction system height is not limited. Coupling this Hi-Ram intake with the high flowing LS3/L92 style cylinder heads has outstanding potential for N/A and forced induction applications at a budget-minded cost. Aggressive, bold, race-bred styling will make bad intentions clear for drag race, muscle car, marine, off-road, sandrails, pulling trucks, track, street-rod applications, and more! • The base is designed to be modular in configuration to accept a wide range of carbureted and EFI tops and to be attractive to builders and fabricators as the foundation for custom induction systems. • Runner length and the tapered cross-section designed to perform well for a wide range of engine configurations • Cast aluminum construction. • Intended for use on N/A or forced induction engines in the 6.0 to 7.0+ liter range, max power at 7000-8000+RPM.
    • Runner Length – 6.50”, As-Cast Runner Cross-Sectional Area – Tapered 4.25 in² to 2.77 in²
    • Plenum Top Gasket Type – 3/32” Round O-ring Cord
    • Mounting Flange Gasket Type – Standard LS3 Molded O-Ring
    • Port Size – 2.49” Height x 1.21” Wide
    • Base Plenum Top Mounting Flange Height – 8.42” to the lifter valley cover flange on engine block.
    • Height (Carbureted or EFI, 2x4V Top Mount & Blank) – 11.08” to the lifter valley cover flange on engine block.

      • Extra Information

      Brand:
      Holley
      pdm:Basic Operating RPM Range:
      3500-8000 R3
      pdm:Brand:
      Holley
      pdm:Carburetor Flange:
      Square/4150
      pdm:Carburetor Studs Included:
      No
      pdm:Category Filter:
      Intake Manifolds
      pdm:Clearance Category:
      Intake Manifolds
      pdm:Color:
      Natural
      pdm:Construction:
      Cast
      pdm:EGR Port:
      No
      pdm:Emission Code:
      4
      pdm:Engine:
      GM LS3/L92
      pdm:Finish:
      Silver
      pdm:Flange Style:
      4150 Square Bore
      pdm:Front Height:
      11.08 inch
      pdm:Front Maximum Height:
      11.08 IN
      pdm:Fuel Injectors Included:
      No
      pdm:Fuel Rail(s) Included:
      No
      pdm:Fuel System Type:
      Carb
      pdm:Gasket Or Seal Included:
      No
      pdm:Grade Type:
      Performance
      pdm:Intake Port Gasket(s) Included:
      No
      pdm:Manifold Type:
      Hi-Ram
      pdm:Material:
      Aluminum
      pdm:Nitrous Bung(s) Included:
      No
      pdm:Plenum Finish:
      Natural
      pdm:Product Type:
      Intake Manifold
      pdm:Rear Height:
      11.08 inch
      pdm:Rear Maximum Height:
      11.08 IN
      pdm:Removable Runners:
      No
      pdm:RPM Power Band:
      3500-8000 RPM
      pdm:Sale Category:
      Air and Fuel Delivery
      pdm:Single Or Dual Plane Type:
      Single Plane
      pdm:Throttle Body Included:
      No
      pdm:Warning:
      California Proposition 65
      pdm:Warranty:
      Limited 90 Day
      pdm:line_code:
      HLY
      pdm:internal_sku:
      300-113
